Introduction to the 2024 MakeX Challenge Arena Upgrade Kit - Energy Innovator
This kit does not include the MakeboX.
1. Basic information
| Name | 2024 MakeX Challenge Arena Upgrade Kit - Energy Innovator |
|---|---|
| SKU | P1090059 |
| EAN | 193122018647 |
| Package type | Paper box |
| Package size (mm) | 100×100×1580 (map) |
| 305×196×203 (flat beam locks) | |
| 380×180×180 (hanging basket) | |
| 365×3550×3100 (other parts-1) | |
| 1040×370×265 (other parts-2) | |
| 1030×75×78 (other parts-3) | |
| Gross weight (including packaging) | 88.04 kg (194.09 lb) |
| Others | Remote control and battery not included |
2. Overview
This kit is designed for users with the 2022 MakeX Challenge Energy Innovator Kit. With this kit, they can participate in the 2024 competition.
3. Parts list
Make sure the following parts are included in the kit. If there is any missing part, contact our after-sales service or distributors.
| Name | Quantity |
|---|---|
| Flat beam 160 | 70 |
| Flat beam 220 | 14 |
| Flat beam 293 | 18 |
| Flat beam 960 | 14 |
| Octagonal pillar-45 | 24 |
| Octagonal pillar-250 | 12 |
| Octagonal pillar-960 | 16 |
| Flat beam lock | 250 |
| Octagonal pillar cover | 116 |
| Polygonal board A | 2 |
| Polygonal board B | 2 |
| Short board A | 4 |
| Short board B | 12 |
| Short board C | 2 |
| Short board D | 10 |
| Short board E | 10 |
| Short board F | 12 |
| Long board A | 6 |
| Long board B | 4 |
| Long board C | 6 |
| Long board D | 4 |
| Long board E | 2 |
| Long board F | 2 |
| Long board G | 8 |
| Long board H | 2 |
| MakeX board blue & black | 1 |
| MakeX board red & black | 1 |
| MakeX sticker red/blue | 6 |
| Hanging basket | 2 |
| Plate A | 12 |
| Plate B | 2 |
| Square beam 0808-056 | 12 |
| Beam 0808-024 | 6 |
| Beam 0412-036 | 12 |
| Beam 0412-092 | 12 |
| Slide beam 0824-144 | 6 |
| Hinge | 12 |
| Coil spring | 12 |
| Wheel | 4 |
| Screw M3*6 | 4 |
| Screw M4*8 | 64 |
| Screw M4*10 | 40 |
| Screw M4*16 | 60 |
| Screw M4*22 | 80 |
| Rectangular nut M4 | 32 |
| Hex lock nut M4 | 150 |
| Hex stud M4*32 | 16 |
| Plastic ring 472 mm | 18 |
| Plastic ring 473 mm | 25 |
| Shaft collar | 4 |
| Flange bearing | 24 |
| Map | 1 |
| Double-sided fabric tape | 1 |
| Transparent tape | 1 |
| 3M double-sided nano tape | 1 |
| Yellow cone | 6 |
| MakeX blue disc | 37 |
| MakeX red disc | 37 |
| Hex Allen key T30 | 1 |
| Screwdriver hex 2.5 mm & cross | 1 |
| Hex key 1.5 mm | 1 |
| Hex key 2.5 mm | 1 |
| Wrench 5 mm & 7 mm | 1 |
4. Assembly instructions
After checking the number of parts, refer to the following document to assemble the 2024 MakeX Challenge Ultimate Winner Arena. 2024 MakeX Challenge Ultimate Winner Arena Assembly Instructions.pdf
